Samsung Xpress SL-M2070F, SL-M2070FW fix firmware [chipless]

.

Order

To create a fix firmware you need to send the data of your printer:

1. Exact printer model
2. Firmware version
3. Machine Serial Number
4. CRUM Number (Toner chip)

To check printer reports (in order not to make a mistake in the data) we recommend use the free program Printer Reports by ORPYS, it has the ability to save reports, you can send this report to us

Instruction (Manual) for program firmware

1. Connect printer to computer and turn ON
2. Extract the archive and drag and drop file M2070F_V3.00.01.xx.hd on usbprns2.exe
    - Wait for the printer to done programming (1-2 minutes) and then it will reboot itself
3. Enter printer into Download Mode [forced mode]
    - Turn printer OFF (by button «POWER»)
    - Press and hold the button [Stop] after [Power] ,
    - As soon as [Press Stop to download mode] appears on the display
    - Quickly release all buttons and quickly press the [Stop] button again.
    - Printer will show massage [Wait Image]»
4. Drag and drop file P_NU_XXXXXXXXXXX_M2070F_V3.00.01.XXx.hd on usbprns2.exe
    - Wait for the printer to done programming (1-2 minutes) and then it will reboot itself
    - After the firmware, you need to glue tape of toner chip and not allow other chips
5. Done, the firmware is finished.

P/S: After the firmware, we recommend disconnecting the CRUM connector from the mainboard

Instruction (Manual) for program original firmware

1. Enter printer into Download Mode
2. Download and extract the archive with original firmware
3. Drag and drop file M2070F_V3.00.01.xx.hd on usbprns2.exe

Original firmware You can download in this Page

Enter to Download Mode [forced mode]

    - With the printer turned off, press and hold the button [Stop] after [Power] ,
    - As soon as [Press Stop to download mode] appears on the display
    - Quickly release all buttons and quickly press the [Stop] button again.
    - Printer will show massage [Wait Image]
